System Main Processor HI3520DV400 Operating System Embedded LINUX Video Input Normal Mode: Analog: 8*(TVI/AHD: 5M@12fps; AHD/TVI/CVI: 4M@15fps; AHD/TVI: 3M; AHD/TVI/CVI: 1080P/720P; Analog: 960H) Analog +Network: 2*Analog(5MP)+7*network(MAX 5MP),4*Analog(5MP)+5*network(MAX 5MP),6*Analog(5MP)+3*network(MAX 5MP) Network: 12*5MP/4MP/3MP/1080P/960P/720P(Total incoming bandwidth ≤48M) Input 8CH BNC Signal Type Analog/AHD/CVI/TVI 2.0/TVI 3.0/Network Output 1HD,1 VGA, CVBS Audio Input 2 Channel, RCA Two-way Audio NO Output 1 Channel, RCA Alarm / Event Sensor Input 4 CH Output 1 CH Motion Detection 8 Channel (max 12 Channel in pure network mode) Trigger Events Recording, Email, Screen tips, Buzzer, Push notifications (motion detection) Email Alarm Send Image to The Designated E-mail Network Interface 1 RJ45 10M/100M Adaptive Ethernet Interface Network Functions TCP/IP, HTTP, UPnP, DNS, NTP, SMTP, PPPoE, DHCP, FTP, DDNS, RTP, RTSP, RTCP DDNS Dyndns, changeip, no-ip, Oray, A-PRESS, MYQSEE, SKDDNS, SMART-EYES, ZEBEYE Web Browser IE8-11, Google Chrome (lower than Ver44), Firefox (lower than Ver53) CMS Software Support Windows 7/ Windows 8/Windows 10 Extra Stream CIF/D1(1~25fps) Smart Phone iPhone, ipad, Android, Android pad Playback & Backup Decode Capability 2CH 1080P@30fps Sync Playback Pure Analog: 8CH 960H@25fps, 8CH 720P@15fps, 7CH 1080N@15fps, 7CH 5M_LITE@6fps, 7CH 4M_LITE@8fps, 7CH 3M_LITE@10fps Mixture mode: 4CH D1@25fps, 2CH 1080P@25fps, 1CH 5MP@25fps Pure Network: 4CH D1@25fps, 2CH 1080P@25fps, 1CH 5MP@25fps Remote Playback 4 Channel / 1Channel Search Mode ALL, Channel, Manual, Time, Date, Motion Detection Playback Functions Play, Pause, Stop, Fast play, Slow play, Rewind, Single frame forward/back, Digital Zoom, Full screenDigital Zoom, Full screen Smart Phone Playback 4 Channel Backup Mode USB Device(with fomat FAT 32 )/Network/FTP Display VGA Resolution: 1920 × 1080P/60Hz, 1280 × 1024/60Hz, 1280 × 720 60Hz,1024 × 768/60Hz HD Output Resolution:1920 × 1080P/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz,1024 × 768/60Hz Display Split 16 Channel/9 Channel/8 Channel/4 Channel / 1Channel Privacy Masking 3 Rectangular Zones (Each camera) OSD Camera title, Time, Video loss, Alarm, Motion detection, Recording General Language Simplified Chinese, Traditional Chinese, English, Polish, Czech, Russian, Thai, Hebrew, Arabic, Bulgarian, German, French, Portuguese, Turkic, Spanish, Italian, Hungarian, Romanian, Korean, Dutch, Greek, Vietnamese, Japanese UTC Control YES USB Interface 2 USB 2.0 Interfaces Power consumption DC 12V/2A ≤6W (Without Hard Disk) Working Environment -10~55℃/10~90% Dimension (W×D×H) 260*215*43(mm) Weight 2kg (Without HDD)
