المواصفات
مسح الخيارات
ztf-10
ZTF-10
Fingerprint Users
1000
Password user
1000
Attendance Records
100,000
Verification
Fingerprint , password
Verification Time
˃ 1.0s
Flash Rejection Rate
˂0.01%
Flash Acceptance Rate
˂ 0.0001 %
Fingerprint Sensor
Optical Sensor
Screen
2.8 inches ( Color Display )
Display Language
English
Communication
RS485 , USB Drive/Link , TCP/IP
Working Humidity
20%- 60%
Working Temperature
0˚C - 50˚C
Power Supply
9V DC
Idle Current
400mA
Working Current
500mA
Sound Indicator
Buzzer , voice
Access Control
Built-in
Battery Backup
Optional
Server Connection
Auto Push Technology
Wi –Fi Connectivity
Optional
GPRS
2G/3G/4G (Optional )
ztf-20cb
ZTF-20CB
Fingerprint User
3000
Password User
3000
Attendance Records
100,000
Verification
Fingerprint, ID card , Password
Verification Time
˃ 1.0s
False Rejection Rate
˂ 0.01%
False Acceptance Rate
˂ 0.0001%
Fingerprint Sensor
Optical Sensor
Screen
2.8 inches ( color Display)
Display Language
English
Communication
RS485, USB Drive/Link, TCP/IP
Working Humidity
20%-60%
Working Temperature
0˚C-50˚C
Power Supply
9VDC
Idle Current
400mA
Working Current
500mA
Sound Indicator
Buzzer ,Voice
Access Control
Built-in
Battery Backup
Optional
Serve Connection
Auto Push Technology
WI-FI Connectivity
Optional
GPRS
2G/3G/4G(Optional)
ztf-40fb
ZTF- 40FB
Face capacity
1000
Card capacity
5000
Fingerprint capacity
5000
Max Attendance log
300.000
Management log
10000
Identify mode
Face , fingerprint , card , password and combinations
Display language
English , Thai , Arabic and so on
LED
1(Red – Green dual color )
Wiegand input
Inside and outside Wiegand (26/34)
Communication
TCP/IP , WIFI (optional )
U- disk
Supported
Audio output
Voice Interface
Battery
3 Hours Battery Backup (optional )
Working voltage
DC 9V ± 5%(current : below 1.5A )
Working Temperature
-10˚c ̴ + 60˚c
Working humidity (RH )
20% ̴ 80%
Search attendance log
Support (After authentication, user can look his / her attendance logs .)
Self – test function
Support
Power management
Sleep mode
FAR/ FRR
0.001/1 (%)
Identify speed
≤ 1.0 seconds
Intelligent adaptation function
Built in
Matching mode
Supports 1:N
FAR /FRR
0.00001/0.1(%)
Identify speed
≤ 1.0 second (when enrolled 5000 fingerprints )
Fingerprint input angel
360˚ (any angle )
Intelligent adaption function
support
Matching mode
Support 1 : N
zta-80ft
ZTA-80FT
User Registration Capacity
1000
Face Registration Capacity
1000
User record/management record
100.000
Language
English , Thai , Spanish, Arabic and so on
Access control function
Essential opening door function , optional control gate/time management / anti-submarine/Duress Alarm function
Attendance function
Attendance(on/off duty)time quantum
Alarm function
yes
Power management function
Sleeping function
U disk upload/ Download function registration information record
yes
Dynamic IP Allocation
Yes(optional M1 card or ID card)
Camera
Tow high definition camera
Infrared lamp
1 imported ultra bright lamp four white light
Unch card function
yes
Displayer
Color screen 2.8 inch TFLCD
Touch screen
yes
Body Induction
Yes
LED lights
Two (Red ,Green)
Input parts
Awg26/34 input (can be external card reader model )
Professional access control function
yes
Communication mode
TCP-IP , WIFI (Optional ) , RS485
U Disk interface
Yes(Remark : only support FAT32 file system)
Voice output
yes
Algorithm version
Facev4.0
FAR/FRR
0.01%/1%
Matching Speed
≤1.0second
Smart update function
yes
Face recognition mode
Support 1:Nor 1:1
size
L73×W46×H187MM
zta-70
ZTA-70
Fingerprint Users
3000
Password User
3000
Attendance Records
100.000
Fingerprint Verification
Mode1:1,1:N
Working Mode
Offline/Online
Verification
Fingerprint , ID Card , Password
Verification Time
>1.0s
False Rejection Rate
<0.01%
False Acceptance Rate
<0.0001%
Fingerprint Sensor
Optical Sensor
Screen
3 inches(Color Display)
Display Language
English
Communication
RS485,USB Drive/Link ,TCP/IP
Working Humidity
20%-60%
Working Temperature
0˚C-50˚C
Power Supply
12v DC
Idle Current
400mA
Working Current
500mA
Sound Indicator
Buzzer, Voice
Access Control
Built-in
Access Control
Directly control of door lock/Indirectly control of door lock via Wiegand access controller. Support 50 access time zones , anti-pass back
Battery Backup
Optional
Server Connection
Auto Push Technology
ztf-30wb
ZTF-30WB
Fingerprint Users
3000
Password Users
3000
Attendance Records
100,000
Verification
Fingerprint , Password
Verification Time
˃ 1.0s
False Rejection Rate
˂ 0.01%
False Acceptance Rate
˂ 0.0001%
Fingerprint Sensor
Optical sensor
Screen
2.80 inches ( color Display )
Display Language
English
Communication
RS485, USB Drive/Link, TCP/IP ,WIFI,P2S,GPRS
Working Humidity
20%-60%
Working Temperature
0˚C-50˚C
Power Supply
9V DC
Idle Current
400mA
Working Current
500mA
Sound Indicator
Buzzer, Voice
Access Control
Built-in
Battery Backup
With battery
Server Connection
Auto Push Technology
Wi-Fi Connectivity
Optional
GPRS
2G/3G/4G (Optional )
ztf-50f
ZTF-50F
Face capacity
1000
Card capacity
5000
Fingerprint capacity
5000
Max Attendance log
300,000
Management log
10000
Identify mode
Face , fingerprint , card , password and combinations
Display language
English , Thai , Spanish, Arabic and so on
LED
1(Red – Green dual color )
Wiegand input
Inside and outside Wiegand (26/34)
Communication
TCP/IP , WIFI (optional )
U- disk
Supported
Audio output
Voice Interface
Battery
3 Hours Battery Backup (optional )
Working voltage
DC 9V ± 5%(current : below 1.5A )
Working Temperature
-10˚c ̴ + 60˚c
Working humidity (RH )
20% ̴ 80%
Search attendance log
Support (After authentication, user can look his / her attendance logs .)
Self – test function
Support
Power management
Sleep mode
FAR/ FRR
0.001/1 (%)
Identify speed
≤ 1.0 seconds
Intelligent adaptation function
Built in
Matching mode
Supports 1:N
FAR /FRR
0.00001/0.1(%)
Identify speed
≤ 1.0 second (when enrolled 5000 fingerprints )
Fingerprint input angel
360˚ (any angle )
Intelligent adaption function
support
Matching mode
Support 1:N
ztf-60ft
ZTF-60FT
Function
Description
Display Dimensions
4.3”TFT Capacitive Color Touchscreen
Cameras
Dual Infrared , Duel HD Camera
Fingerprint Sensor
Optical (Dim )
Verification Modes
Face, fingerprint, ID card (IC card optional),PIN, combination )
Communication Protocol
TCP/IP, WI-FI (Optional)
USB Functions
USB Flash drive download/upload, firmware upgrade
Recognition Speed
≤1s
Record Query
Supported
Machine Learning Fingerprint
Supported
Biometric Datebase Lookup
1: N,1:1
Face Capacity
1500
Fingerprint Capacity
5000
ID card Capacity
5000
PIN Capacity
5000
Photo Storage Capacity
10000(Including enrollment and realtime photo record)
Time/Management Record
500000/10000
Bell Functions
Internal bell (preset time intervals )
Voice
Chinese/English /Korean and so on
Display Language
Simplified Chinese/English/Korean and more ( customizable )
Self-testing
Supported
Power Management
Sleep Mode
Alarm
Record Full and Threaten
