Camera Industrial-grade embedded HiSilicon CPU Operating System Embedded Linux System resources Simultaneous multi-channel real-time recording, playback, network operation, USB backup Interface Operator interface 16-bit true color graphic menu operation interface, support mouse operation 1/4 split screen Video Video input (IP) 4*1080P Video standards PAL(625TVL,50f/s)；NTSC(525TVL,60f/s) Video compression H.264 Display quality Max 1920*1080 Playback quality 1*1080P Decode 1*1080P Motion detection Support(depend on camera) Audio Audio compression G.711A Intercom Unsupport Record & playback Recording mode Manual>Alarm>Dynamic Detection>Timing Local payback 1*1080P/4*D1 Search mode Search by Time/Calendar/Event/Channel Storage & Backup Space occupation Video：CIF 4~5G/day*channel， D1 8~10G/day*channel； 960H 12G~20G/day*channel 720P 20~30G/day*channel； 1080P ~40G/day*channel； Audio：691.2M/day*channel Record storage HDD、Network Backup mode Network backup, USB hard disk, USB burner, SATA burner External interface Video output 1ch HDMI,1chVGA Full HD output Audio I/O 0/0 Alarm I/O 0/0 Network interface 1*RJ45 10M/100M Adaptive Ethernet port USB interface 2*USB2.0 ports HDD 1 SATA General PTZ control Control PTZ device by network ONVIF Support Power supply 12V/2A Power Consumption <10W(Without HDD) Work environment Temperature:0℃-＋55℃ , Humidity:10%－90%RH , Atm:86kpa－106kp Dimension 255*50*220mm Weight 2KG

System Main processor Industrial-grade embedded HiSilicon CPU Operating System Embedded Linux System resources Simultaneous multi-channel real-time recording, playback, network operation, USB backup Interface Operator interface 16-bit true color graphic menu operation interface, support mouse operation Preview 1/4/8split screen Video Video input (IP) 8*1080P、8*720P Video standards PAL(625TVL,50f/s)；NTSC(525TVL,60f/s) Video compression H.264 Display quality Max 1920*1080 Playback quality 2*1080P Decode 2*1080P Motion detection Support(depend on camera) Audio Audio compression G.711A Intercom Unsupport Record & playback Recording mode Manual>Alarm>Dynamic Detection>Timing Local payback 2*1080P Search mode Search by Time/Calendar/Event/Channel Storage & Backup Space occupation Video：CIF 4~5G/day*channel， D1 8~10G/day*channel； 960H 12G~20G/day*channel 720P 20~30G/day*channel； 1080P ~40G/day*channel； Audio：691.2M/day*channel Record storage HDD、Network External interface Video output 1ch HDMI,1chVGA Full HD output Network interface 1*RJ45 10M/100M Adaptive Ethernet port USB interface 2*USB2.0 ports HDD 1 SATA 2 SATA General PTZ control Control PTZ device by network ONVIF Support Power supply 12V/2A 12V3A Power Consumption <10W(Without HDD) Work environment Temperature:0℃-＋55℃ , Humidity:10%－90%RH , Atm:86kpa－106kp Dimension 255*50*220mm Weight 2KG 3KG

System Main Processor Hi3536 Industrial-grade embedded HiSilicon CPU Operating System Embedded Linux System Resources Simultaneous multi-channel real-time recording ,playback, network operation, USB backup Interface Operator Interface 16-bit true color graphic menu operation interface, support mouse operation Preview 1/4/8/16/24/32 split screen Video Video Input (IP) 8*4K/32*5M/16*3M Access bandwidth 384Mbps Forwarding bandwidth 307Mbps Video Standards PAL (625TVL, 50f/s); NTSC (525TVL, 60f/s) Video Compression H.265/H.264 Display Quality Max 4K Playback Quality 4K/5MP/3MP Decode 2ch*4K/4ch*5MP/8ch*3MP Motion Detection Depend on camera Audio Audio Compression G.711A Intercom Support Record & playback Recording Mode Manual>Alarm>Video Detection>Continuous Local Payback 2ch*4K/4ch*5MP/8ch*3MP Search Mode Search by Time/ Calendar/ Event/ Channel Storage & Backup Space Occupation Video: CIF 4~5G/day*channel, D1 8~10G/day*channel; 960H 12G~20G/day*channel 720P 20~30G/day*channel; 1080P ~40G/day*channel; Audio: 691.2M/day*channel Record Storage HDD\ Network Backup Mode Network backup, USB hard disk, USB burner, SATA burner External interface Video Output 1ch HDMI, 1ch VGA Full HD Output Audio I/O 1/1 Alarm I/O unsupport Network Interface 1*RJ45 10M/100M /1000M Adaptive Ethernet port USB Interface 1*USB2.0 port,1*USB3.0 port（Reserved 2 pre interface） Wireless 3G, WIFI (Extend Via USB) HDD 8*SATA (Up to 8TB for each disk) General PTZ Control Control PTZ device by network ONVIF Support Power Supply DVR dedicated ATX Power Supply Power Consumption <10W (Without HDD) Work Environment Temperature: 0℃-＋55℃, Humidity: 10%－90%RH, Atm: 86kpa－106kp Dimension 443*92*400mm Weight Around 7KG

System Main Processor Hi3536 Industrial-grade embedded HiSilicon CPU Operating System Embedded Linux System Resources Simultaneous multi-channel real-time recording, playback, network operation, USB backup Interface Operator Interface 16-bit true color graphic menu operation interface, support mouse operation Preview 1/4/8/16/24/32/64 split screen Video Video Input (IP) 24ch*5M/36ch*4M/64ch*1080P Video Standards PAL (625TVL, 50f/s); NTSC (525TVL, 60f/s) Video Compression H.265/H.264 Display Quality Max 4K Playback Quality 5M/4M/1080P Decode 4*5M/9*4M/8*1080P Motion Detection Depend on camera Audio Audio Compression G.711A Intercom Support Record & playback Recording Mode Manual>Alarm>Video Detection>Continuous Local Payback 4*5M/9*4M/8*1080P Search Mode Search by Time/ Calendar/ Event/ Channel Storage & Backup Space Occupation Video: CIF 4~5G/day*channel, D1 8~10G/day*channel; 960H 12G~20G/day*channel 720P 20~30G/day*channel; 1080P ~40G/day*channel; Audio: 691.2M/day*channel Backup Mode Network backup, USB hard disk, USB burner, SATA burner Record Storage HDD\ Network External interface Video Output 1ch HDMI, 1ch VGA Full HD Output Audio I/O 1/1 Alarm I/O 16/4 Network Interface 1*RJ45 10M/100M /1000M Adaptive Ethernet port USB Interface 1*USB2.0 port,1*USB3.0 port（Reserved 2 pre interface） Wireless 3G, WIFI (Extend Via USB) HDD 8*SATA (Up to 8TB for each disk) General PTZ Control Control PTZ device by network ONVIF Support Power Supply DVR dedicated ATX Power Supply Power Consumption <10W (Without HDD) Work Environment Temperature: 0℃-＋55℃, Humidity: 10%－90%RH, Atm: 86kpa－106kp Dimension 443*92*400mm Weight Around 7KG

System Main Processor Hi3536D HiSilicon CPU Operating System Embedded Linux System Resources Simultaneous multi-channel real-time recording, playback, network operation, USB backup Interface Operator Interface 16-bit true color graphic menu operation interface, support mouse operation Preview 1/4/8/16 split screen Video Video Input (IP) 16*5M@15fps/8*5M/16*1080P Access bandwidth 64Mbps Forwarding bandwidth 64Mbps Video Compression H.265/H.264 Display Quality Max:1920*1080 Playback Quality 5MP/1080P Decode 1*5M/2*1080P Motion Detection Depend on camera Audio Audio Compression G.711A Intercom Support Record & playback Recording Mode Manual>Alarm>Video Detection>Continuous Local Payback 1*5M/2*1080P Search Mode Search by Time/ Calendar/ Event/ Channel Record Storage HDD\ Network Backup Mode Network backup, USB hard disk, USB burner, SATA burner External interface Video Output 1ch HDMI, 1ch VGA Full HD Output Audio I/O 0/0 Alarm I/O unsupport Network Interface 1*RJ45 10M/100M Adaptive Ethernet port USB Interface 2*USB2.0 port, HDD 1*SATA (Up to 8TB for each disk) General PTZ Control Control PTZ device by network ONVIF Support Power Supply DC 12V/ 2A Power Consumption <10W (Without HDD) Work Environment Temperature: 0℃-＋55℃, Humidity: 10%－90%RH, Atm: 86kpa－106kp

System Main processor Industrial-grade embedded HiSilicon CPU Operating System Embedded Linux System resources Simultaneous multi-channel real-time recording, playback, network operation, USB backup Interface Operator interface 16-bit true color graphic menu operation interface, support mouse operation Preview 1/4/8/16 split screen Video Video input (IP) 16*5MP\8*4K Video standards PAL(625TVL,50f/s)；NTSC(525TVL,60f/s) Video compression H.265/H.264 Display quality Max 4K Playback quality 4*5MP Decode 4*5MP Motion detection Support (depend on camera) Audio Audio Compression G.711A Intercom Support Record & playback Recording mode Manual>Alarm>Dynamic Detection>Timing Local payback 4*5MP Search mode Search by Time/Calendar/Event/Channel Space occupation 5MP ~60G/day*channel； Audio：691.2M/day*channel Record storage HDD, Network Backup mode Network backup, USB hard disk, USB burner, SATA burner External interface Video output 1ch HDMI,1chVGA Full HD output Audio I/O 1/1 Network interface 1*RJ45 10M/100M Adaptive Ethernet port Network Interface 16 POE ports Support network cable to provide power supply and transmits video POE power supply distance 100m USB interface 2*USB2.0 ports General PTZ control Control PTZ device by network ONVIF Support Power supply 48V 5A Work environment Temperature:0℃-＋55℃ , Humidity:10%－90%RH , Atm:86kpa－106kp Dimension 380*55*280mm Weight 4kg

System Main Processor Hi3536C HiSilicon CPU Operating system Embedded Linux Codec H.265 /H.264 System Resources Simultaneous multi-channel real-time recording, playback, network operation, USB backup Interface Operator Interface 16-bit true color graphic menu operation interface, support mouse operation Preview 1/4/9/16/32 split screen Video Monitor quality VGA (1080P at most); HDMI (4K at most) Video Input (IP Cameras) 8ch*4K/ 32ch*5M/ 32ch*1080P Access Bandwith 300Mbps Forwarding bandwidth 240Mbps Video compression H.265 /H.264 Display quality Max: 4K Local Playback 1ch*4K/ 2ch*5M/ 4ch*1080P Motion Detection Depend on camera Audio Audio Compression G.711A Intercom support Record & playback Recording Mode Manual>Alarm>Dynamic Detection>Timing Video storage HDD, network Backup mode Network, USB hard disk, USB burner, SATA burner Search Mode Search by Time/ Calendar/ Event/ Channel External interface Video Output 1ch HDMI, 1ch VGA Audio I/O 1/1 Alarm I/O 0/0 Network Interface 1*RJ45 10M/100M/1000M Adaptive Ethernet port USB Interface 2* USB 2.0 ports ESATA NO Serial Interface NO HDD 2*SATA (Each Up to 8TB) General ONVIF Support Power Supply 12V/3A Power Consumption <10W (Without HDD) Work Environment Temperature: 0℃-＋55℃, Humidity: 10%－90%RH, Atm: 86kpa－106kp
