IMAGE Lens Optical Zoom 30X, 4.3~129mm Angle of View 65.1~2.23°(H) Image Sensor Type 1/2.8” SONY STARVIS CMOS Sensor Image Sensor Pixels 1945(H)x1097(V) Min. Illumination Color : 0.35Lux / BW : 0.013Lux@50IRE, 0Lux(IR LED On) Scanning Mode Progressive Scan Wide Dynamic Range True WDR 100db Day and Night Mode True Day & Night Noise Reduction 3DNR Digital Zoom 16X Exposure Control Auto, Manual, Shutter Priority, Iris Priority White Balance Control Auto, Fluorescent, Incandescent, Outdoor, Manual Back Light Compensation Yes Image Euect Flip Shutter Speed 25/30fps : Auto(1/30,000~x8sec), Manual 50/60fps : Auto(1/50,000~x8sec), Manual IR Illuminator Quantity Synchronized IR LED, Fixed IR LED IR Illuminator Angle 5~60° IR Illuminator Distance Up to 400m VIDEO/AUDIO Compression H.264(Baseline, Main, High Profile), MJPEG Bitrate Control CVBR, VBR Resolution 1920x1080, 1280x1024, 1280x720/960, 704x480/576, 640x360/480, 320x240 Frame Rate Max. 50/60fps Streaming 50/60fps(Dual Stream : H.264x1, MJPEGx1) 25/30fps(Triple Stream : H.264x2, MJPEGx1) Audio Compression G.711 Audio Streaming 2 Way PTZ FUNCTION Pan Range 360˚Endless Pan Speed Max. 380˚/sec.(Preset) Tilt Range -10~190˚ Tilt Speed Max. 380˚/sec.(Preset) Preset 256 Tour 8 Pattern 8 Home Function Yes SYSTEM Video Contents Analysis DIS, Defog, Face Detector, Tampering, Line Detector, Field Detector Motion Detection Area 16 Programmable Area(Include Area 8, Exclude Area 8) Privacy Masking 16 Programmable Zone FTP Uploading MJPEG Event Notification E-mail, FTP, Notification Server, XML Notification, Audio Alert, AIHM Audio Alert User-Defined 3 Audio Files Login Authority Administrator, Operator, Guest Event Buuering          FTP Pre : 30sec, Post : 30sec Event Buuering          SD Record Pre : 10sec, Post : 60sec Manual Trigger 4 Programmable Trigger Security Multi User Authority, IP Filtering, HTTPS, SSL Network Time Sync NTP Server, Synchronized Computer, Manual Software Reset Restart, Reset, Factory Default Hardware Factory Reset Yes Auto Recovery Backup, Restore Remote Upgrade Web Browsing(IE, Chrome, Safari, Firefox), SmartManager, NC-Titanium SD Recording Mode Event, Continuous

Model ZTGIP-PTZ4K IMAGE Lens Optical Zoom 30X, 6~180mm Angle of View Image Sensor 55.4~2.7°(H) 1/1.7” SONY STARVIS CMOS Sensor Min. Illumination Scanning Mode Color : 0.75Lux@50IRE / BW : 0Lux(IR LED On) Progressive Scan Wide Dynamic Range True WDR Day and Night Mode True D/N(Auto, Day, Night) Noise Reduction 2DNR, 3DNR Digital Zoom Yes(ROI) Exposure Control Auto, Iris Priority White Balance Control Auto, Manual Metering Mode Spot, Center, Average Image Effect Flip, Defog Flicker Free Mode 50Hz, 60Hz Shutter Speed Auto(1/10,000~1sec) IR Illuminator Quantity Synchronized IR LED, Fixed IR LED Distance Up to 350m VIDEO/AUDIO Compression H.264(Baseline, Main, High Profile), MJPEG Bitrate Control CBR, CVBR Resolution 3840x2160, 3072x2048, 2592x1944/1520, 2560x1440, 1920x1080, 1440x1080, 1280x1024/720, 1024x768, 800x600/480, D1, 640x480, 400x240, CIF Frame Rate Max. 25/30fps(PAL/NTSC) Streaming Quad Stream(H.264/H.265x3, MJPEGx1) Audio Compression G.711 Audio Streaming 2 Way PTZ FUNCTION Pan Range 360˚Endless Pan Speed Max. 380˚/sec.(Preset) Tilt Range -10~90˚ Tilt Speed Max. 380˚/sec.(Preset) Preset 256 Tour 8 Pattern 8 Home Function Yes SYSTEM Video Contents Analysis Tampering, iVMD, Intrusion Detector Motion Detection Area 16 Programmable Area(Include Area 8, Exclude Area 8) Privacy Masking 16 Programmable Zone Smart Codec Hi-Stream FTP Uploading MJPEG Event Notification E-mail, FTP, Notification Server, XML Notification, Audio Alert Audio Alert User-Defined 3 Audio Files Login Authority Administrator, Operator, Guest Event Buuering FTP Pre : 30sec, Post : 30sec SD Record Pre : 10sec, Post : 60sec Manual Trigger 4 Programmable Trigger Security Multi User Authority, IP Filtering, HTTPS, SSL Network Time Sync NTP Server, Synchronized Computer, Manual Software Reset Restart, Reset, Factory Default Hardware Factory Reset Yes Auto Recovery Backup, Restore Remote Upgrade Web Browsing(IE, Chrome, Safari, Firefox), SmartManager SD Recording Mode Event, Continuous NETWORK Protocol TCP/IP, UDP, IPv4/v6, HTTP, HTTPS, QoS, FTP, UPnP, RTP, RTSP, RTCP, DHCP, ARP, Zeroconf, Bonjour Client Software Web, SmartManager, Client S/W, Mobile S/W Max. User Connection Live : 10 Users, Playback : 3 Users API Support Open API, Onvif Compliance Mobile Support (Android, iOS) EXTERNAL IN/OUT Audio 1 Input, 1 Output(RCA Mono Jack) Alarm 4 Input, 1 Output Ethernet RJ-45(10/100Base-T) u-SD Card SDHC, SDXC ETC Operating Humidity 0~90% RH(Non-Condensing) Operating Temperature -30~+55℃ Power Supply PoE(IEEE 802.3bt Compliance, Class5), 12VDC Power Consumption 500mA(28W)@PoE 2.3A(28W)@12VDC Dimension 201.8(Ø)x317.8(H)mm Net Weight Approx. 5.1kg Ingress Protection IP66
