Fingerprint Users 1000 Password user 1000 Attendance Records 100,000 Verification Fingerprint , password Verification Time ˃ 1.0s Flash Rejection Rate ˂0.01% Flash Acceptance Rate ˂ 0.0001 % Fingerprint Sensor Optical Sensor Screen 2.8 inches ( Color Display ) Display Language English Communication RS485 , USB Drive/Link , TCP/IP Working Humidity 20%- 60% Working Temperature 0˚C - 50˚C Power Supply 9V DC Idle Current 400mA Working Current 500mA Sound Indicator Buzzer , voice Access Control Built-in Battery Backup Optional Server Connection Auto Push Technology Wi –Fi Connectivity Optional GPRS 2G/3G/4G (Optional )

Fingerprint User 3000 Password User 3000 Attendance Records 100,000 Verification Fingerprint, ID card , Password Verification Time ˃ 1.0s False Rejection Rate ˂ 0.01% False Acceptance Rate ˂ 0.0001% Fingerprint Sensor Optical Sensor Screen 2.8 inches ( color Display) Display Language English Communication RS485, USB Drive/Link, TCP/IP Working Humidity 20%-60% Working Temperature 0˚C-50˚C Power Supply 9VDC Idle Current 400mA Working Current 500mA Sound  Indicator Buzzer ,Voice Access Control Built-in Battery Backup Optional Serve Connection Auto Push Technology WI-FI Connectivity Optional GPRS 2G/3G/4G(Optional)

Face capacity 1000 Card capacity 5000 Fingerprint capacity 5000 Max Attendance log 300.000 Management log 10000 Identify mode Face , fingerprint , card , password and combinations Display language English , Thai , Arabic and so on LED 1(Red – Green dual color ) Wiegand input Inside and outside Wiegand (26/34) Communication TCP/IP , WIFI (optional ) U- disk Supported Audio output Voice Interface Battery 3 Hours Battery Backup (optional ) Working voltage DC 9V ± 5%(current : below 1.5A ) Working Temperature -10˚c ̴ + 60˚c Working humidity (RH ) 20% ̴ 80% Search attendance log Support (After authentication, user can look his / her attendance logs .) Self – test function Support Power management Sleep mode FAR/ FRR 0.001/1 (%) Identify speed ≤ 1.0 seconds Intelligent adaptation function Built in Matching mode Supports 1:N FAR /FRR 0.00001/0.1(%) Identify speed ≤ 1.0 second (when enrolled 5000 fingerprints ) Fingerprint input angel 360˚ (any angle ) Intelligent adaption function support Matching mode Support 1 : N
