IMAGE SENSOR 1/2.9" 2.1Megapixel SONY Exmor CMOS EFFECTIVE PIXELS 1920 (H) × 1080 (V) SCANNING SYSTEM Progressive RESOLUTION Full HD 1080P VIDEO OUTPUT AHD / TVI / CVI / CVBS S/N (Y SIGNAL) More than 50dB Min. ILLUMINATION 0.02Lux(Sens-UP x30) IRIS ADJUSTMENT AUTO LENS 2.8~12mm DC Auto IRIS LENS (ICR) ELECTRONIC SHUTTER AUTO(1/30~1/50,000) OSD LANGUAGE ENG / CHN1 / CHN2 / GER / FRA / ITA / SPA / POL / RUS / POR / NED / TUR BACKLIGHT COMPENSATION OFF / BLC / HSBLC DAY & NIGHT EXT / AUTO / COLOR / BW AUTO GAIN CONTROL LEVEL (0~15) Adjustment WHITE BALANCE ATW / AWC/ INDOOR / OUTDOOR / MANUAL / AWB DNR (2D+3DNR) OFF / LOW / MIDDLE / HIGH D-WDR OFF / ON PRIVACY MASKING OFF / ON (Programmable 4 Zones) DEFOG OFF / AUTO SENS-UP OFF / x2~x30 MOTION OFF / ON (Programmable 4 Zones) DIGITAL EFFECT OFF / MIRROR / V-FLIP / ROTATE DPC LIVE DPC / DPC SET COMMUNICATION UTC (OPTION) IR LED 30EA up to 30 M IR DISTANCE INPUT VOLTAGE DC 12V(±10%) POWER CONSUMPTION IR OFF :150mA (MAX) / IR ON : 400mA (MAX) OPERATING TEMP. / HUM. -10ºC ~ +50ºC / MAX 90% RH STORAGE TEMP. / HUM. -20ºC ~ +60ºC / MAX 90% RH
